RUSHFPV 1.2/1.3GHz 800mW VTX Module
Of the 10 other 1.2/1.3 GHz analog video transmitters in our database, none has a lower maximum power than the 1.2/1.3GHz 800mW VTX Module (800 mW, 29 dBm) and 10 a higher one; the class median is 2000 mW. The 1.2/1.3GHz 800mW VTX Module steps through 25 / 200 / 400 / 800 mW, which is 14 / 23 / 26 / 29 dBm: the top level is 15 dB above the lowest, about 5.7x the free-space range on the same antennas.
| System | analog |
|---|---|
| Max power | 800 mW |
| Power levels | 25 / 200 / 400 / 800 mW |
| Frequency range | 1.08-1.36 GHz |
| Band | 1.2/1.3 GHz |
| Input voltage | 7-30V |
| Channels | 8 |
Other transmitters in this band, side by side: 1.2-1.3 GHz FPV VTX compared.
Choosing between systems? See analog vs DJI vs Walksnail vs HDZero.
Where this data comes from
Silkscreen on the SMA board: power steps PIT / 25 / 200 / 400 / 800 mW, band A with eight channels (1080, 1120, 1160, 1200, 1240, 1280, 1320, 1360 MHz), DC 7-30 V. An earlier U.FL revision of the same board is pictured on the same page with nine channels (1258 MHz added) and a 7-36 V input; where the two revisions disagree the figures above are the SMA one's. Sold in an SMA and a U.FL version, so the connector column stays empty - it is a choice, not this board's socket. Output above the lowest step is licensed spectrum in most countries; the module's own label carries that reminder.
